Wombat Creek is a H0 (1:87) scale model of a fictional town situated somewhere in the Victorian Goldfields, Australia.

The time is 1963. Geelong wins the VFL Championship against Hawthorn (109– 60). John F. Kennedy is assassinated in Dallas. ValentinaTeresjkova is the first woman in Space. The men behind The Great Train Robbery get £2.6 million from a Royal Mail train heading from Glasgow to London.

The town consists of several buildings. The “Wombat Creek Bank and Gold Exchange” is a prominent building in the town centre. You will also find several other commercial buildings; among them the daily newspaper“W.C. Chronicle”(colloquial known as the "Toilet Paper") and “Wombat Creek Brewing Company” (Famous for the “Wombat Bitter”). “The Big Nugget Gold Mine” is situated at the Western outskirts of town near the small Chinatown. The War Memorial is in a small park along East Street.


The town’s mayor Alfred Campbell together with his son David Campbell owns several businesses, including the bank, the pub and the newspaper. AC/DC basically run the town and make most decisions on behalf of the rest of Wombat Creek’s residents, who, on the other hand, are too busy with their own businesses.


The mayor’s latest initiative is Wombat Creek Tramways. Wombat Creek doesn’t really need a tram system, but AC reckons tramways will improve the town’s reputation. Partly because of limited funds the tramways' construction and rolling stock depend heavily on second-hand requirements from other Australian and overseas tramways.

Narrow gauge turntable – part 3

Text and photos from Wombat Creek Consolidated Mines Pty Ltd Posted on Fri, September 23, 2022 22:24:00

When life serves you lemons, you make lemonade. When life serves you polypropylene plastic, you … don’t make a turntable!

wct 220921

Nothing seems to stick to this sort of plastic (except the label), so I had to start from scratch with the turntable. His time I used styrene plastic and the outcome is far better. The turntable still has to be painted and railings fitted along the top.

wct 220922a

The turntable is turned with a worm drive. The axle is a knitting pin kindly donated by my wife. The turntable can be turn fully 360 degrees, but this will rarely happens. Because of a steep (and invisible) incline near the Little Nugget Mine all locomotives will run chimney first towards the mines to avoid the top of the firebox being exposed.

wct 220922b

The tracks are down and powered. Unfortunately my first attempt got a couple of wires mixed up. As a result a steam locomotive ended up in the creek twice! All is now sorted. The locomotive shed houses the two large steam engines. The smaller one will require a second shed at the track to the left of the bigger shed. This track will also be used for a coal stand and a water tank.



Narrow gauge turntable – part 2

Text and photos from Wombat Creek Consolidated Mines Pty Ltd Posted on Mon, September 19, 2022 20:24:35

Construction of the turntable got under way today. I planned to take a few photos of the process, but I got carried away with the work itself, so I have only a few photos to show. The project is progressing as expected but not as fast as I had hoped for.

wct 220919

The first image is of the container lid,, which will form the pit for the turntable. The ‘bridge’ is cut from the bottom of the container. A slim 50 mm bolt has been put through the centre of the ‘bridge’.

The second image shows the pit in place.

Quite a few stages were done before the third image. A section of standard gauge track was cut into two and forms the guide rail at the bottom of the pit. Probably slightly over-size, but I expected it would be too difficult to keep a smaller rail in place. Two length of narrow gauge rails have been super glued to the ‘bridge’. Wires have been soldered to the rails on the bridge and in the pit. The ‘pit rails’ will be powered. The ‘bridge wires’ will somehow glide on top of lower rails and thereby supply power to the ‘bridge’. A slim sheet of plastic has been slit in place along the wall of the pit to conceal the threads of the lid. The third image shows the turntable and the tracks leading towards it installed. Also the track into the shed is in place.

The final image is similar to the third, but with the shed in place.

Tomorrow’s work will include laying the remaining track and power the tracks and the turntable. Finally the turntable has to be detailed .



Narrow gauge turntable – part 1

Text and photos from Wombat Creek Consolidated Mines Pty Ltd Posted on Sun, September 18, 2022 12:20:05
wct 220918

An empty vitamin D container, a top from a milk carton, a worm drive and a 50 mm bolt with nuts. Could this – with a few more bits and pieces – become the long needed turntable for the mining railway? I hope the next few days will show.



Finding the right order – part 5

Text & photos from Wombat Creek Tramways Posted on Wed, September 14, 2022 18:48:35
wct 220914

The bridge for the tramways over Wombat Creek has been completed. The retaining wall has been capped and the left bank of the creek is in place. The building to the left belongs to the narrow gauge railway and will serve as a locomotive shed and repair shop.



Finding the right order – part 4

Text and photos from Wombat Creek Consolidated Mines Pty Ltd Posted on Sun, September 11, 2022 12:07:41

The bluestone retaining wall along the creek has been erected. Only the capping stones at the top are missing. The photo shows the purpose of a relative long wall. It sits along and hides the control panels.

Next step would be the second wall/pier supporting the bridge, but..

To get easy access to the dirt road along the creek, it better wait, but…

The dirt road will cross the railway on the other side, but…

The tracks will have to be put down before the road, but…

The tracks will cross the creek, so a small bridge has do be built first!

Complicated? Not really if you get the order right.

wct 220909

The access road to the Big Nugget Mine is almost completed with sand from Phillip Island, cloured ‘teddy bear fur’ and potting mix from – well a bag. The potholes are topped with clear PVA. As seen on the photo the road is in a poor condition. On his way back from the mine Mr. Howard had a minor accident with his ute slipping into the creek. The railway to and from the mine is definitely needed when the mine is fully operational.



Finding the right order – part 3

Text and photos from Wombat Creek Consolidated Mines Pty Ltd Posted on Mon, August 29, 2022 17:49:05

The bluestone retaining wall along the creek has been erected. Only the capping stones at the top are missing. The photo shows the purpose of a relative long wall. It sits along and hides the control panels.

Next step would be the second wall/pier supporting the bridge, but..

To get easy access to the dirt road along the creek, it better wait, but…

The dirt road will cross the railway on the other side, but…

The tracks will have to be put down before the road, but…

The tracks will cross the creek, so a small bridge has do be built first!

Complicated? Not really if you get the order right.

Making progress! Some tracks have been put down in the Big Nugget Mine. The original track plan has just a loop without a siding. This will give the locomotive a lot of waiting time whilst wagons are emptied or, as an alternative, a lot of light engines going to and from the mine. To avoid this the chief engineer has decided to purchase more points. This is the reason for not completing the loop at the moment, but with the ‘outer’ track already in place, work on the dirt road can progress.

wct 220829

How the locomotive got onto the track is a mystery with no rail connection past the points!



Extending the fleet

Text and photos from Wombat Creek Consolidated Mines Pty Ltd Posted on Fri, August 26, 2022 18:35:46

The chief engineer of the mining railway was advised a steam locomotive was up for auction. The description said ‘used, but in running condition’. Until now the fleet of locomotives has consisted of a small 0-6-0T and a larger 0-6-2T. The smaller locomotive is fine for shunting around the main rail yard, but it will struggle with larger trains up to the mines. Therefore the chief engineer put a small offer in for a second 0-6-2T and to his surprise he won the auction.
The locomotive has arrived. Put on the tracks it would not move an inch! An electrical connection had to be re-adjusted. Further work has to be done. The locomotive has a bad habit of stalling at the points. The photo shows the recent arrival between the two older locomotives.

wct 220825


Finding the right order – part 2

Text and photos from Wombat Creek Consolidated Mines Pty Ltd Posted on Fri, August 19, 2022 17:21:58

The bluestone retaining wall along the creek has been erected. Only the capping stones at the top are missing. The photo shows the purpose of a relative long wall. It sits along and hides the control panels.

Next step would be the second wall/pier supporting the bridge, but..

To get easy access to the dirt road along the creek, it better wait, but…

The dirt road will cross the railway on the other side, but…

The tracks will have to be put down before the road, but…

The tracks will cross the creek, so a small bridge has do be built first!

Complicated? Not really if you get the order right.

The above text is from a previous post. The bridge has been adapted from a drawing of Victorian Railways’ ‘Superstructure for Plated “I” Beam Bridge’. Not a huge project.

wct 220818
Railway Bridge no. 2 across Wombat Creek
